ArilSystemTM Two Heads JU-28
ArilSystemTM
Two Heads JU-28
Technical Information
Rate
Up to 28 pomegranates/minute
Approx. 1008kg pomegranates /hour
Operators
Minimum 2
Room Space
Minimum 40m2
Air Pressure (at the machine)
Compressor Capacity: 180 CFM
Pressure: 8 Bar (per extractor)
Oil free, dry Air, in accordance with FDA regulations
Water
Pressure: Fresh water supply at 3 to 4 atmospheres
Water-Drain Inlet Capacity: 4.5m3/hour per extractor
Electrical Supply
3 phase, 380V, 16A
Rate
Up to 28 pomegranates/minute
Approx. 1008kg pomegranates /hour
Operators
Minimum 2
Room Space
Minimum 40m2
Air Pressure (at the machine)
Compressor Capacity: 180 CFM
Pressure: 8 Bar (per extractor)
Oil free, dry Air,
in accordance with FDA regulations
Water
Pressure: Fresh water supply
at 3 to 4 atmospheres
Water-Drain Inlet Capacity:
4.5m3/hour per extractor
Electrical Supply
3 phase, 380V, 16A
